Loop Tack 2000

Machine Details

• Rugged construction, capable of withstanding the abuse of the production environment
• Digital speed and distance control
• Automated test sequence
• Easy sample setup using a removable grip makes testing quick and consistent
• Capable of performing 5 inch or 7 inch loop tests
• Test Methods – D6195, FTM9, or custom test methods with either 5 or 7 inch loops
• Selectable speed range from 6 to 30 ipm (150 - 762 mm/min) for custom test methods.  Increment value is 1 ipm or 1 mm/min.
• Selectable dwell time from 0 to 30 seconds (in increments of 1 second) for all other test methods
• 10 pound load cell is included with the machine (2 and 5 pound load cells are optional)
• Designed to use 1x3 or 1x6 inch panels up to .25 inch thick
• Accurate to ± 0.1% of load cell range
• Operating temperature range 32° - 150° F (0° - 70° C)
• Capable of stand-alone operation with integrated touch display
• Data can be downloaded to EZ Data software for complete data management
• 5.7 inch touch screen display
• Universal input voltage from 85-265 VAC(50/60Hz)

Data Acquisition System

• The ChemInstruments electronic data acquisition system is a state-of-the-art microprocessor controlled force measurement package that combines accuracy with ease of use. This system simultaneously controls test motion, reads the force of a test from a load cell, digitally displays it and also stores that data in its memory.
• Samples at 400Hz, 8 samples are collected, averaged and stored as a data point. A test will generate a data point every 20ms
• Displays a graph of all measured force values upon completion of a test
• Displays the high and low measured force results immediately upon completion of a test
• Export data by USB connection to a local PC with our EZ Data software
• Displays test values in grams, kilograms, ounces, pounds or Newtons

EZ-Data

• EZ Data Compatible Remote setup, operational control and enhanced data collection are all possible when coupled with our EZ Data management software. This application requires an external PC. (See more information about the EZ-Data product)

Calibration Service

• Calibration Service is available for this equipment. Contact us for more information
• Load cell is easily removable for yearly calibration

LT-2000 Equipment Manual

Accessories

Essential:

• Test panel - 1" x 6" (25mm x 150mm)
• Specimen tape cutter - 1" (25mm)
  (Above items are all included in our accessory package - LTA.)



Non-Essential:

• EZ-Data data management software
• Various test panel sizes and materials
• Various sized specimen tape cutters
• Test panel holder

Options

• Additional load cell capacities available: 2 and 5 pounds
• PSTC and TLMI testing manuals

Specifications

• Height: 18" (46 cm)
• Width: 13" (33 cm)
• Depth: 16" (41 cm)
• Weight: 25 lbs (12 Kg)

Methods

Some of the more popular test methods that this device is capable of performing:

• PSTC: 16-B
• ASTM: D 6195B
• FINAT: FTM-9
• AFERA: 5014

Quickly and efficiently determine the tack or "grab" of an adhesive with the ChemInstruments Loop Tack Tester. This compact tack testing machine meets PSTC, ASTM and TLMI specifications. Simple to operate, it can be used stand-alone or connected to EZ Data Lab Management software.
